0.600 To 1.199MM Deep Diamond Drawing Dies With Natural Synthetic Diamond Core

I'm Online Chat Now

0.600 To 1.199MM Deep Diamond Drawing Dies With Natural Synthetic Diamond Core

0.600 To 1.199MM Deep Diamond Drawing Dies With Natural Synthetic Diamond Core
0.600 To 1.199MM Deep Diamond Drawing Dies With Natural Synthetic Diamond Core

Large Image :  0.600 To 1.199MM Deep Diamond Drawing Dies With Natural Synthetic Diamond Core

Product Details:
Place of Origin: China
Model Number: 0.012~1.20 mm
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiable
Packaging Details: Carton, Box
Delivery Time: 5-8 work day
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200pcs each day
Detailed Product Description
Diamond Drawing Dies: Single Crystal Diamond Dies Material: Natural Or Synthetic Diamond Core
Hole Size: 0.012~1.20 Mm Surface Treatment: Polishing
Casing: Stainless Steel Type: Mold Tool
Highlight:

0.6MM Diamond Drawing Dies

,

1.199MM Diamond Drawing Dies

,

Synthetic deep drawing dies

Diamond Drawing Dies With Natural or Synthetic Diamond Core



1. Description:



For fine wire and ultrafine wire applications demanding a superior wire surface finish, nothing performs better than a single crystal natural or synthetic diamond die. Mount the diamond inside the die casing to ensure precise profiling, exceptionally accurate hole sizing and maximum wearability that all combine to yield unmatched wire quality. Used in fine and ultrafine wire sizes, or as finish-dies when wire surface quality is critical.



2. Specification:

Size Range Natural Diamond Dies
(ND Dies)
Mono Diamond Dies
(MD Dies)
Φ mm Φ inch
0.012 - 0.059 0.0005 - 0.0023
0.060 - 0.099 0.0024 - 0.0039
0.100 - 0.599 0.0039 - 0.0236
0.600 - 1.199 0.0236 - 0.0472
... ... ... ...



3. Application:



Magnet wire, medical wire, plated-copper wire, wet-drawn stainless steel wire and wire drawn of precious metals.



4. Advantages:



You get the very best performance for optimum wire reduction uniformity and wire roundness, minimum die pull and virtually flawless wire surface finish.
