Product Details:
Payment & Shipping Terms:
|
| Synthetic Diamond Powder: | Diamond Micron Powder | Sizes: | 0-0.25 ~ 40-60 |
|---|---|---|---|
| Application: | Grinding, Poshing | Package: | Bag, Bottle |
| Transport: | By Air, By Sea | ||
| Highlight: | W0/0.25 rvd diamond powder,Grinding rvd diamond powder,Synthetic diamond polishing powder |
||
Diamond Micron Powder for Polishing and Grinding, Synthetic Diamond Powder
1. Description:
1) A-shape Diamond Micron Powder
Product Characteristics: Very blocky shape, strictly narrow PSD, tiny impurities (inner and outer); better dispersion and high wear-resistence.
Recommended Applications: Metal bonded products, electroplated diamond products; grinding and polishing on: precise machinery, optical glass, fine ceramics, gem stone, semi-conductor and etc.
2) B-shape Diamond Micron Powder
Product Characteristics: Blocky shape, narrow PSD, low impurities (inner and outer).
Recommended Applications: Cutting, lapping, grinding and polishing on: silicon glass, optical glass, ceramic, and etc.
3) C-shape Diamond Micron Powder
Product Characteristics: Economic type product with irregular shape and normal PSD.
Recommended Applications: Lapping, grinding or polishing on: PCD, ceramics, stone and other workpieces.
2. Specifications:
| Grain Size | 0 - 0.25 | 0 - 0.5 | 0 - 1 | 0.5 - 1.5 | 0 - 2 | 1 - 2 | 1 - 3 | 2 - 4 | 3 - 6 | 4 - 8 |
| μm | 5 - 10 | 6 - 12 | 8 - 12 | 8 - 16 | 10 - 20 | 15 - 25 | 20 - 30 | 20 - 40 | 30 - 40 | 40 - 60 |
Remark: Other sizes can be supplies on request.
