HRC45 To 65 PCD Cutting Tool Blanks Pcd Pcbn Cutting Tools For Machining

I'm Online Chat Now

HRC45 To 65 PCD Cutting Tool Blanks Pcd Pcbn Cutting Tools For Machining

HRC45 To 65 PCD Cutting Tool Blanks Pcd Pcbn Cutting Tools For Machining
HRC45 To 65 PCD Cutting Tool Blanks Pcd Pcbn Cutting Tools For Machining HRC45 To 65 PCD Cutting Tool Blanks Pcd Pcbn Cutting Tools For Machining

Large Image :  HRC45 To 65 PCD Cutting Tool Blanks Pcd Pcbn Cutting Tools For Machining

Product Details:
Place of Origin: China
Model Number: Round Disc, Cutting Tips
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1 PCS
Packaging Details: Plastic box, Carton
Delivery Time: 5-8 workdays
Payment Terms: T/T, Western Union, L/C
Supply Ability: 1500 pieces per month
Detailed Product Description
PCD Cutting Tool Blanks: PCBN Cutting Tool Blanks CBN Content: 50%, 70% 90%
Series: Solid CBN, Tungsten Carbide Backed CBN Shape: Round
Application: Cutting Transport: By Air
Highlight:

HRC45 PCD Cutting Tool Blanks

,

HRC65 PCD Cutting Tool Blanks

,

pcd pcbn cutting tools For Machining

PCBN Cutting Tool Blanks For Machining Hard Ferrous Materials



1. Description:



PCBN, with characteristic of high hardness, high wear resistance and high thermal stability, is made of selected CBN powder and sintered at high pressure and high temperature, with metals or ceramic binders. PCBN is ideal for tools in machining of high hardness and hard processed ferrous materials (HRC45-65).



2. Specification:



CBN Content Type Property Application
90%

Solid PCBN

Carbide backed PCBN

Excellent wear resistance and anti-chipping, better impact resistance Gray cast iron, powder metallurgy metals
70%

Solid PCBN

Carbide backed PCBN

Good wear resistance and impact resistance, better chemical stability Hardened steel,Mould steel,
50%

Solid PCBN

Carbide backed PCBN

Excellent chemical stability and good thermal stability

Chilled steel

























3. Application:



PCBN is typically used to machine brake discs, engine blocks, engine cylinder liners, brake drums, flywheels, valve seats and guides, gears, mold and die parts, etc.



4. Advantage:

  • Multiple grades of PCBN blanks and wide range of application
  • High cost-effective, Easy Processing, good performance, High wear resistance, Consistence
