Product Details:
Payment & Shipping Terms:
|
| Wire Drawing Dies: | Twisting Dies | Size: | Customized Size |
|---|---|---|---|
| Casing: | Stainless Steel | Type: | Mold Tool |
| Application: | Twisting | Transport: | By Air |
| Highlight: | 0.35mm Wire Drawing Dies,35mm Wire Drawing Dies,stainless steel die D12 |
||
Wire Drawing Dies, Twisting Dies
We provide a variety of grades of high-performance cemented carbide die materials, such as precise stamping die materials, cold heading dies and drawing dies. PM cemented carbide provides the products with reasonable hardness, transverse rupture strength and fracture toughness for different working conditions, and designs reliable, optimized and stable production and manufacturing processes, which helps customers to manufacture high-quality mold
1. Description:
In combination with wire twisting dies, which twist many wires together, compacting dies close the gaps between wires by exerting external force.
2. Specifications:
Available Sizes: 0.35~35.0mm.
3. Application:
The resulting strand wires are used as power line cables, wiring harnesses for automobiles, wire ropes, and for other purposes.
| inches | mm | ADDMA | Maximum Diameter |
| 0.0039-0.0157 | 0.100-0.400 | D6 | 0.4 |
| 0.0079-0.0315 | 0.200-0.800 | D12 | 0.8 |
| 0.0079-0.0394 | 0.200-1.000 | D12 | 1.0 |
| 0.0197-0.0591 | 0.500-1.500 | D15 | 1.5 |
| 0.0197-0.0591 | 0.500-1.500 | D15 | 1.5 |
| 0.0315-0.0787 | 0.800-2.000 | D18 | 2.0 |
| 0.0315-0.0787 | 0.800-2.000 | D18 | 2.0 |
| 0.0472-0.1181 | 1.200-3.100 | D21 | 3.1 |
| 0.0472-0.1181 | 1.200-3.100 | D21 | 3.1 |
| 0.0591-0.1732 | 1.500-4.400 | D24 | 4.4 |
| 0.0591-0.1732 | 2.000-4.400 | D24 | 4.4 |
| 0.1299-0.2126 | 3.300-5.400 | D27 | 5.4 |
| 0.1299-0.2183 | 3.300-5.800 | D27 | 5.8 |
| 0.2008-0.2992 | 5.100-7.600 | D30 | 7.6 |
| 0.3150-0.4331 | 8.000-11.000 | D33 | 11.0 |
| 0.3150-0.4409 | 8.000-11.200 | D30 | 11.2 |
| 0.3150-0.4724 | 8.000-12.000 | D33 | 12.0 |
| 0.3150-0.4921 | 8.000-12.500 | D33 | 12.5 |
| 0.3150-0.5000 | 8.000-12.700 | D36 | 12.7 |
