D24 2.000 To 4.400MM PCD Wire Diamond Drawing Dies For Stainless Steel Wires

I'm Online Chat Now

D24 2.000 To 4.400MM PCD Wire Diamond Drawing Dies For Stainless Steel Wires

D24 2.000 To 4.400MM PCD Wire Diamond Drawing Dies For Stainless Steel Wires
D24 2.000 To 4.400MM PCD Wire Diamond Drawing Dies For Stainless Steel Wires D24 2.000 To 4.400MM PCD Wire Diamond Drawing Dies For Stainless Steel Wires

Large Image :  D24 2.000 To 4.400MM PCD Wire Diamond Drawing Dies For Stainless Steel Wires

Product Details:
Place of Origin: China
Model Number: D6 - D36
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Packaging Details: Carton, Box
Delivery Time: 5-10 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200 pieces per day
Detailed Product Description
PCD Drawing Dies: Stainless Steel Material: Polycrystalline Diamond
Hole Size: 0.10mm-12.7mm Surface Treatment: Polish
Transport: By Air Warranty: 1 Year
Highlight:

D24 diamond drawing dies

,

2MM diamond drawing dies

,

4.4MM wire drawing die

PCD Drawing Dies for Stainless Steel Wires



1. Description:



PCD wire drawing die is a normal wire tool made by PCD blanks. When pass through a group of PCD dies, the wire gradually deforms then becomes thiner and thiner, finally comes to target size. Stainless steel is hard so the dies will bear much press in wire drawing process. In this case, firstly of all ,the PCD blanks should be with high strength then reduction angle shoule be smaller.



2. Specifications:



inches mm ADDMA Maximum Diameter
0.0039-0.0157 0.100-0.400 D6 0.4
0.0079-0.0315 0.200-0.800 D12 0.8
0.0079-0.0394 0.200-1.000 D12 1.0
0.0197-0.0591 0.500-1.500 D15 1.5
0.0197-0.0591 0.500-1.500 D15 1.5
0.0315-0.0787 0.800-2.000 D18 2.0
0.0315-0.0787 0.800-2.000 D18 2.0
0.0472-0.1181 1.200-3.100 D21 3.1
0.0472-0.1181 1.200-3.100 D21 3.1
0.0591-0.1732 1.500-4.400 D24 4.4
0.0591-0.1732 2.000-4.400 D24 4.4
0.1299-0.2126 3.300-5.400 D27 5.4
0.1299-0.2183 3.300-5.800 D27 5.8
0.2008-0.2992 5.100-7.600 D30 7.6
0.3150-0.4331 8.000-11.000 D33 11.0
0.3150-0.4409 8.000-11.200 D30 11.2
0.3150-0.4724 8.000-12.000 D33 12.0
0.3150-0.4921 8.000-12.500 D33 12.5
0.3150-0.5000 8.000-12.700 D36 12.7

Note: The above hole sizes are recommended for soft wire.In case of hard wire drawing,the maximum hole size should not exceed 65% of them.





3. Application:



Suitable for drawing of hard wires, such as stainless steel and etc.



4. Advantage:



PCD (Polycrystalline Diamond) is a kind of synthetic diamonds. The carbon molecule forms PCD under ultra high temperature and press. Strong bond between diamond particles make PCD have higher abrasive resistance,hardness as well as good thermal conductivity.
